MF-1915YR

Mingfeng 19 LED focus moving head light

Voltage: AC110V-240V, 50/60HZ

Power: 300W

Lamp beads: OSRAM 19*15W (4IN1-R?G?B?W)

Channel: 16CH/24CH

Control mode: DMX/automatic/sound control

Horizontal scan: 540° (16-bit precise scan) electronic error correction.

Vertical scan: 270° (16-bit precise scan) electronic error correction.

Strobe: 1-25 times/second or random

Display Screen: LCD/English

Performance and Features

DMX512 Channel

X-axis 540 degrees, with self-recovery closed-loop system

Y-axis 270 degrees, with self-recovery closed-loop system

Horizontal and vertical independent linear speed regulation

Scanning fine-tuning, X/Y axis 16BIT scanning subdivision precise positioning

Lighting angle: 8-50°

Electronic dimming: 10-100% linear adjustment

Multiple strobes: 1-18 times/second (conventional strobe, lightning strobe, random strobe, sudden dark and bright strobe, sudden bright and dark strobe.)

Linear adjustment RGB256×256×256 infinitely variable color mixing

Control mode: 16-channel DMX512 signal control mode, master-slave control mode

(Multiple synchronization) with self-propelled program voice control mode.

Closed light positioning operation function.

The forward and reverse directions of the X/Y axis of a single lamp or group of lamps can be edited on the console.

Packing size: 415×315×470mm

Net weight: 10kg

Gross weight: 11.7kg
